404
1) Angle indicator:
Precise and intuitive display current angle information.
2) Film control buttons:
There are bed control buttons in the inner and outer side of cold side, portable operation.
3) Weighing and bed leaving alarm function:
It can display the patient's weight in real time and continuously detect weight changes, and can always detect the Patient's bed status.
4) Hand controller
Graphic buttons are intuitive and easy to use, and have common functions for controlling beds.
5) Display operating panel
The end of the bed with a UI display, full function integration, safe and efficient
6) CPR function
The emergency situation is quickly returned to the flat lying state, one-chck operation, safe and comfortable.
7) Double -sided Casters
The double -sided mute foot wheel can set the lock and free state, tolerate acid and alkali, resist corrosion.
8) Night lamp
Durable LED lights can illuminate the areas where patients enter and exit safely.
9) Display operating panel
Visualized 7-inch display operation panel further enrichesthe user's operating experience. Personal information moduleregistration patientinformation, bed control module posturedata data, clearly displays and sets the bed status and angle parameters, and the weigh- ing function module records the patient's real-time weight data.
10) Seven functions and efficient switch on demand
This is an electric bed that integrates multiple functions such as back lifting, leg lifting, assisted side turning, integrated lifting, trendelenburg and reverse trendelenburg, one-button formation and one-button lying down, and is equipped with a doctor-patient interaction system, so that patients can receive safer, more timely and effective treatment.
11) Bad control function
The hand controller on the side of the bed and the control panels on the inside and outside of the bedside guardrail, bringing a safer and more comfortable use experience to medical care staff and patients.
|
Model |
CM-EHB-5ND |
CM-EHB-5NE |
CM-EHB-7NG |
CM-EHB-7NH |
|
Bed body size mm （long x width, tolerance±30mm) |
2270×1080 |
2295×1180 |
||
|
Bed surface size mm （long x width, tolerance±30mm) |
1995×920 |
1995×980 |
||
|
Minimum height of bed surface mm （not including mattress, tolerance±30mm) |
480 |
|||
|
Bed surface lifting stroke range mm (tolerance±30mm) |
230 |
|||
|
Backboard folding angle range （tolerance±3°) |
0~70 |
|||
|
Folding angle range of thigh plate （tolerance±3°) |
0~30 |
|||
|
Folding angle range of calf plate （tolerance±3°) |
0~12 |
|||
|
Turn over folding angle range （tolerance±3°) |
No |
0~20 |
||
|
Reverse trendelenburg angle range （tolerance±3°) |
0~12 |
|||
|
The maximum angle of trendelenburg |
≥12 |
|||
|
Braking method |
Central brake |
|||
|
Measured noise of bed dB |
≤65 |
|||
|
Weight measurement digital display |
No |
Yes |
No |
Yes |
|
UI display |
No |
Yes |
Yes |
Yes |
